Continuous Slot Wedge Wire Well Screens, Vadodara, Gujarat, India

Water well screens, also called Vee wire well screens, are made of V or wedge shaped wires around an internal array of longitudinal support rods. It is designed to serve as the intake portion of wells constructed in unconsolidated or semi-consolidated aquifers. This design supplies a continuous slot openings, which allows water to enter the well freely in ample quantities and keeps the majority of sand and gravels out of the well at the same time.

Specifications

Common Specifications of Stainless Steel Wedge Wire Water Well Screens
Size (inch)	O.D. (mm)	Slot Size (mm)	Length (m)	Collapse Strength (Bar)	Tensile Weight (ton)	Wrap Wire (width × Height) (mm)	Support Rods (mm)
3-1/2	88.9	1.0	2.9	>22	10.2	2.3 × 3.5	3.8 mm / 22
4-1/2	114.3	1.0	2.9	>28	11.5	2.3 × 3.5	3.8 mm / 22
6-5/8	168.3	0.75	5.8	>40	12.8	2.3 × 3.5	3.8 mm / 32
6-5/8	168.3	1.0	5.8	>33	12.8	2.3 × 3.5	3.8 mm / 32
6-5/8	168.3	0.63	5.8	>83	45	3.2 × 6.0	6.0 mm*32
8-5/8	219.1	1.0	5.8	>34	21.9	2.3 × 3.5	3.8 mm / 48
8-5/8	219.1	1.0	5.8	>50	38.2	3.0 × 5.0	4.0 mm / 48
8-5/8	219.1	1.0	5.8	>60	46	3.2 × 6.0	5.0 mm / 48
10-3/4	273.1	0.75	5.8	>50	32.9	2.3 × 3.5	4.9 mm / 55
10-3/4	273.1	1.0	5.8	>60	39.5	3.0 × 5.0	4.9 mm / 55

Common Specifications of Stainless Steel Wedge Wire Water Well Screens

Size (inch)	O.D. (mm)	Slot Size (mm)	Length (m)	Collapse Strength (Bar)	Tensile Weight (ton)	Wrap Wire (width × Height) (mm)	Support Rods (mm)
10-3/4	273.1	1.0	5.8	>100	48	3.2 × 6.0	5.0 mm / 55
12-3/4	323.9	1.0	5.8	>120	37.2	3.0 × 5.0	4.0 mm / 50
14	355.6	1.0	2.9	>80	37.8	3.0 × 5.0	4.0 mm / 59

Notes:

• The wedge wire water well screen is commonly made of stainless steel materials.
• The length can be made up to 12 m.
• Slot size may be 0.1 mm to 3.0 mm.

Features

• Inward opening slots (in-flow) prevents sand particles from remaining lodged in screen.
• High efficient and ensures consistent pumping and long well life
• Specially V-shaped wire structure with two point welding prevents plugging and clogging.
• Continuous slot wedge wires provide large open area than perforated metal pipes or slot pipes used in water well applications.
• Strong longitudinal support rods supply excellent pressure-resistant performance
